RECOMMENDED SYSTEM REQUIREMENTS
For Optimal Wireless Performance, use with:
+ Dual Band Adapter (DWA-160)
MINIMUM SYSTEM REQUIREMENTS
+ Cable or DSL Modem
+ Computer with:
- Windows
®
7
3
,Windows Vista
®3
, Windows
®
XP
SP3, or Mac OS
®
X (v10.4)
4
- Internet Explorer v7 or Mozilla Firefox v3.0
- CD-ROM Drive
- Network Interface Card
+ For Internet Access:
- Cable or DSL Modem
- Subscription with an Internet Service
Provider (ISP)
PACKAGE CONTENTS
+ Wireless N Dual Band Router
+ 2 Detachable Antennas
+ CAT5 Ethernet Cable
+ Power Adapter
+ CD-ROM
5
with
- Installation Wizard
- Product Documentation
TECHNICAL SPECIFICATIONS
STANDARDS
+ IEEE 802.11n
+ IEEE 802.11g
+ IEEE 802.11b
+ IEEE 802.11a
+ IEEE 802.3
+ IEEE 802.3u
+ IEEE 802.3ab
DEVICE INTERFACE
+ 4 10/100 LAN Ports
+ 1 10/100 WAN Portß
EXTERNAL ANTENNA TYPE
+ Two (2) Detachable Reverse Antennas
SECURITY
+ Wi-Fi Protected Access (WPA, WPA2)
®
ADVANCED FIREWALL FEATURES
+ Network Address Translation (NAT)
+ Stateful Packet Inspection (SPI)
+ VPN Pass-through / Multi-sessions PPTP / L2TP / IPSec
DEVICE MANAGEMENT
+ Internet Explorer
®
v7 or Later; Mozilla Firefox
®
v3.0 or Later;
or other Java-enabled Browsers
LEDs
+ Power
+ Status
+ WAN (10/100)
+ WLAN (Wireless Connection)
+ LAN (10/100)
CERTIFICATIONS
+ FCC Class B
+ IC
+ Wi-Fi
®
DIMENSIONS
+ Item (WxDxH): 6.2” x 4.7” x 1.2” (157.5mm x 119.4mm x 30.5mm)
+ Packaging (WxDxH): 8.1” x 10.9x 2.6(205.7mm x 276.9mm x 66mm)
WEIGHT
+ Item: 0.47 lbs (213.2grams)
+ Packaging: 1.0 lbs (453.6grams)
OPERATING TEMPERATURE
+ 32°F to 104°F (0°C to 40°C)
WARRANTY
+ 1-Year Limited
2
DIR-815
WHAT THIS PRODUCT DOES
Create a wireless network to share high-speed
Internet access with computers, game consoles,
or media players from greater distances in your
home or office.
WIRELESS N ROUTER BENEFITS
+ Delivers faster speeds
1
and farther range
1
than
previous-generation Wireless G
1
+ Award-winning QoS Engine prioritizes Internet
traffic to enable enhanced gaming and phone
calling (VoIP) experience
+ Easy to install and use with the included Quick
Router Setup Wizard
1
Maximum wireless signal rate derived from IEEE 802.11 specifications. Actual data
throughput will vary. Network conditions and environmental factors, including volume
of network traffic, building materials and construction, and network overhead, lower
actual data throughput rate. Environmental factors will adversely affect wireless
signal range. Wireless range and speed rates are D-Link RELATIVE performance
measurements based on the wireless range and speed rates of a standard Wireless G
product from D-Link. Maximum throughput based on D-Links Wireless N devices.
2
1-Year Limited Warranty available only in the USA and Canada.
3
Computer must adhere to Microsofts recommended System Requirements.
4
The software included with this product is not Mac-compatible.
5
Latest software and documentation are available at http://support.dlink.com.
All references to speed and range are for comparison purposes only. Product
specifications, size, and shape are subject to change without notice, and actual product
appearance may differ from that depicted herein.
©2010 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, the D-Link
logo are registered trademarks of D-Link Corporation or its subsidiaries in the United
States and/or other countries. Other trademarks or registered trademarks are the
property of their respective owners.

Other manuals for D-Link DIR-815

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DIR-815 and is the answer not in the manual?

D-Link DIR-815 Specifications

Wireless Signal Rates IconWireless Signal Rates
IEEE 802.11n 20MHz Channel 1Nss65/72.2 Mbps (max)
IEEE 802.11n 20MHz Channel 2Nss130/144.44 Mbps (max)
IEEE 802.11n 40MHz Channel 1Nss135/150 Mbps (max)
IEEE 802.11n 40MHz Channel 2Nss270/300 Mbps (max)
IEEE 802.11a54 Mbps - 48Mbps - 36Mbps - 24Mbps - 18Mbps - 12Mbps - 9Mbps - 6Mbps
IEEE 802.11g54Mbps - 48Mbps - 36Mbps - 24Mbps - 18Mbps - 12Mbps - 11Mbps - 9Mbps - 6Mbps
Wireless Frequency Range IconWireless Frequency Range
Frequency Range (802.11g/n)2.412GHz to 2.462GHz
Frequency Range (802.11a/n)5.15GHz to 5.825GHz
Transmitter and Antenna IconTransmitter and Antenna
Transmitter Output Power15dBm +/- 2dB
External Antenna TypeTwo (2) undetachable reverse SMA Antennas
Operating Environment IconOperating Environment
Operating Temperature32°F to 104°F (0°C to 40°C)
Humidity95% maximum (non-condensing)
Weight and Dimensions IconWeight and Dimensions
Length6.25 inches (158.87 mm)
Width4.72 inches (120.04 mm)
Height1.27 inches (32.18 mm)
