13
TECHNICAL SPECIFICATIONS
General
Standards IEEE 802.11a/b/g/n
Transmitter Output
Power
• 5GHz 27.1dBm (peak) • 2.4GHz 28.4dBm (peak)
• 5GHz 21.6dBm (average) • 2.4GHz 22.6dBm (average)
Data Transfer Rate • 108Mbps • 48Mbps • 54Mbps • 24Mbps • 36Mbps •
12Mbps • 18Mbps • 9Mbps • 11Mbps • 5.5Mbps •
6Mbps • 1Mbps • 2Mbps
MSC (0-15)
• 130Mbps (270) • 117Mbps (243) • 104Mbps (216) •
78Mbps (162) • 66Mbps (135) • 58.5Mbps (121.5) •
52Mbps (108) • 39Mbps (81) • 26Mbps (54) • 19.5Mbps
(40.5) • 12Mbps (27) • 6.5Mbps (13.5)
Frequency Range 2.4GHz to 2.483GHz
5.180GHz to 5.250GHz and 5.725GHz to 5.825GHz
Modulation
Schemes
BPSK/QPSK/CCK/OFDM
Media Access
Protocol
CSMA/CA with ACK
Security • WPA-Personal • WPA2-Personal • WPA-Enterprise •
WPA2-Enterprise
Physical and Environmental
Operating
Temperature
32°F to 104°F ( 0°C to 40°C)
Humidity 95% maximum (non-condensing)
Dimensions x x mm (W x H x D)
Safety & Emissions • FCC • IC
