Hardware Overview
1 Power LED
A solid green light indicates a proper connection to the
power supply. The light will be solid orange during boot-up
and will blink green during the WPS process.
2 Internet LED
A solid green light indicates a connection to the Internet
port. If the LED is orange, the connection is good but the
router cannot connect to the Internet. If this LED is blinking
orange, this indicates that the on demand” connection
type is set and the Internet connection is idle.
3 WPS Button
Press to start the WPS process. The Power LED will start to
blink green.
4 LAN Ports (1-4)
Connect Ethernet devices such as computers, switches,
and game consoles.
5 Internet Port
Connect your broadband modem to this port using an
Ethernet cable.
6 USB Port
Connect a USB ash drive to share content throughout
your network.
7 Power Button Press to power the router on and o.
8 Power Port Connect the supplied power adapter.
9 Reset Button
Press and hold the reset button with a paper clip for six
seconds to reset the router to the factory default settings.
