D-Link DIR-850L Setup & User Guide

3
HKBN_SETUP_ROUTER_DLINK_ENG_230315
Connecting to D-Link router
2 Connecting to D-Link Router
Make sure you have a LAN cable connected from the HKBN wall plate/ONT to the Internet
port of your D-Link Router (DIR-850L). Using a second LAN cable, connect it from the Router
LAN port to the computer LAN port. Once finished, switch on the power supply for the router
and turn on the computer.
Open your Internet browser, and input [http://192.168.0.1] into the address-bar then press
[Enter]. Leave the password box empty and click [Log In].

D-Link DIR-850L Specifications

Operating Environment

operating temperature	32 ~ 104 °F (0 ~ 40 °C)
non-operating temperature	-4 ~ 149 °F (-20 ~ 65 °C)
operating humidity	10% - 90% non-condensing

Power

input voltage	100~240 V (±20%), 50~60 Hz
output voltage	DC 12 V
output current	2 A

Wireless Specifications

wireless interface 2.4 GHz	IEEE 802.11b/g/n
wireless interface 5 GHz	IEEE 802.11a/n/ac
antenna type	Two dual-band internal antennas (2.4 GHz and 5 GHz)

Weight and Dimensions

dimensions	93 x 116 x 145 mm (3.7 x 4.6 x 5.76 inches)
weight	330 grams (11.6 ounces)
