4
• Users with DSL providers - If you are using a PPPoE connection, you will need
your PPPoE user name and password. If you do not have this information, contact
your Internet provider. Do not proceed until you have this information.
• Users with Cable providers - Make sure you unplug the power to your modem.
In some cases, you may need to turn it o for up to ve minutes.
• Advanced Users - If your ISP provided you with a modem/router combo, you will
need to set it to “bridge” mode so the DIR-859 router can work properly. Please
contact your ISP or refer to the user manual for your modem/router device.
Before you Start
1
Unplug the power to your DSL or Cable modem.
2
Connect an Ethernet cable from the Internet port of the router to the
Ethernet port on your DSL or Cable modem.
Modem
Connect your Router
1 2 3 4 INTERNET 12V --1.5A POWER WPS
Ethernet Port
Modem
Ethernet Cable
DIR-859
Internet Port (yellow)
To Next Page
