D-Link DIR-867 - Before You Start; Connect Your Router

4
• Users with DSL providers - If you are using a PPPoE connection, you will need
your PPPoE user name and password. If you do not have this information, contact
your Internet provider. Do not proceed until you have this information.
• Users with Cable providers - Make sure you unplug the power to your modem.
In some cases, you may need to turn it o for up to 5 minutes.
Before you Start
1
Unplug the power to your DSL or Cable modem.
2
Connect an Ethernet cable from the yellow Internet port of the router to
the Ethernet port on your DSL or Cable modem.
Modem
Connect your Router
4 3 2 1 INTERNET RESET WPS WiFi 12V...1.5A POWER
- • +
Ethernet Port
Modem
Ethernet Cable
DIR-867
Internet Port (yellow)
NOTE: If your DSL or cable
modem uses a battery
backup, please remove
the backup battery and
ensure all lights are o on
the modem. Refer to the
modem’s user manual
if required.
