5D-Link DIR-600 User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
Power LED
A solid light indicates a
proper connection to the
power supply.
Local Network LEDs
A solid light indicates a connection to an
Ethernet-enabled computer on ports 1-4.
This LED blinks during data transmission.
Internet LED
A solid light indicates connection on
the Internet port. This LED blinks
during data transmission.
WLAN LED
A solid light indicates that the wireless
segment is ready. This LED blinks
during wireless data transmission.
