D-Link DNS-313 Technical Specifications

YOUR HARD DRIVE SETUP
WHAT THIS PRODUCT DOES
The DNS-313 1-Bay Network Storage Enclosure,
when used with internal SATA drives,
(1)
enables
hom
es to share documents, music,
photos, and videos across the network and on the
In
ternet so family members,
or friends
can access them. This enclosure allows creation of
a central network point for backing up valuable files.
This device can be used to stream music, photos, and
videos to UPnP AV compatible network media players.
(4)
The DNS-313 can also be used as a portable USB
hard drive and is very handy when you need to store
large files and carry them around.
ROBUST SOFTWARE INCLUDED
The included CD contains the D-Link Click’n Connect
utility to quickly configure your new DNS-313 in
minutes. Our D-Link Click’n Connect walks you
step by step through the installation process to
configure your DNS-313 so that you don’t have to
be a networking expert to get it set up. In addition,
the Easy Search Utility allows you to locate the
DNS-313 anywhere on the network. Once located,
use the utility to map the hard drive so it will appear
in “My Computer” on the PC. Backup software is
also included on the CD. This allows the backup of
valuable files from your computer to the DNS-313
manually, by a schedule, or in real-time. Real-time
backups are a great way to safeguard against
unfortunate accidents that may result in the loss of
precious files.
TECHNICAL SPECIFICATIONS
STANDARDS
+ IEEE 802.3
+ IEEE 802.3u
+ IEEE 802.3ab
+ USB 2.0
SUPPORTED HARD DRIVE TYPE
+ SATA-standard drive of any capacity size
+ 3.5-inch internal
DEVICE INTERFACES
+ 1 10/100/1000 Gigabit Ethernet port
+ 1 USB 2.0 port
+ Power socket for external power adapter
DEVICE MANAGEMENT MANAGEMENT
+ Through Internet Explorer v6 or other Java-enabled browser
+ E-mail alerts
+ Power management
+ iTune and UPnP™ AV Server for streaming media to
compatible Media Players
(2)
+ Built-in FTP server for file access from over the Internet
+ Scheduled downloads from Web or FTP Sites
+ Power management for conserving energy and extending
hard drive life
+ Real time backups with the included backup software
+ Storage permissions for users and groups
+ Multi-language file name support
MINIMUM SYSTEM REQUIREMENTS
+ Computer with:
- 1GHz processor/512MB RAM/200MB of available space
- Windows® Vista, Windows®XP SP2, or Windows 2000 SP4
- CD-ROM drive to view product documentation and
installation software
DIAGNOSTIC LEDs
+ Power + LAN + LAN+ LAN LANLAN
+ HDD HDDHDD
OPERATING TEMPERATURE
+ Operating: 0˚ to 55˚ C (32˚ to 131˚ F)
+ Storage: -20˚ to 70˚ C (-4˚ to 158˚ F)
HUMIDITY
+ Operating: 5% to 90% (non-condensing)
DIMENSIONS
+ 200 (L) x 124 (H) x 49 (W) mm
WEIGHT
+ 1.29Kg
DNS-313 BACK UP AND SHARE DIGITAL FILES
DNS-313
D-Link Worldwide Offices
U.S.A. TEL: 1-800-326-1688 FAX: 1-866-743-4905
Canada TEL: 1-905-8295033 FAX: 1-905-8295223
Europe (U. K.) TEL: 44-20-8955-9000 FAX: 44-20-8955-9001
Germany TEL: 49-6196-77990 FAX: 49-6196-7799300
France TEL: 33-1-30238688 FAX: 33-1-30238689
Netherlands TEL: 31-10-282-1445 FAX: 31-10-282-1331
Belgium TEL: 32(0)2-517-7111 FAX: 32(0)2-517-6500
Italy TEL: 39-02-2900-0676 FAX: 39-02-2900-1723
Sweden TEL: 46-(0)8564-61900 FAX: 46-(0)8564-61901
Denmark TEL: 45-43-969040 FAX: 45-43-424347
Norway TEL: 47-99-300-100 FAX: 47-22-309580
Finland TEL: 358-9-2707 5080 FAX: 358-9-2707-5081
Spain TEL: 34-93-4090770 FAX: 34-93-4910795
Portugal TEL: 351-21-8688493
Czech Republic TEL: 420-(603)-276-589
Switzerland TEL: 41-(0)-1-832-11-00 FAX: 41(0)-1-832-11-01
Greece TEL: 30-210-9914 512 FAX: 30-210-9916902
Luxemburg TEL: 32-(0)2-517-7111 FAX: 32-(0)2-517-6500
Poland TEL: 48-(0)-22-583-92-75 FAX: 48-(0)-22-583-92-76
Hungary TEL: 36-(0)-1-461-30-00 FAX: 36-(0)-1-461-30-09
Singapore TEL: 65-6774-6233 FAX: 65-6774-6322
Australia TEL: 61-2-8899-1800 FAX: 61-2-8899-1868
India TEL: 91-022-26526696 FAX: 91-022-26528914
Middle East (Dubai) TEL: 971-4-3916480 FAX: 971-4-3908881
Turkey TEL: 90-312-473-40-55 FAX: 90-312-473-40-58
Egypt TEL: 202-291-9035 FAX: 202-291-9051
Israel TEL: 972-9-9715700 FAX: 972-9-9715601
LatinAmerica TEL: 56-2-232-3185 FAX: 56-2-232-0923
Brazil TEL: 55-11-218-59300 FAX: 55-11-218-59322
South Africa TEL: 27-12-665-2165 FAX: 27-12-665-2186
Russia TEL: 7-495-744-0099 FAX: 7-495-744-0099 #350
Japan TEL: 81-3-5781-0963 FAX: 81-3-5781-0965
China TEL: 86-10-58635800 FAX: 86-10-58635799
Taiwan TEL: 886-2-6600-0123 FAX: 886-2-6600-8168
Headquarters TEL: 886-2-6600-0123 FAX: 886-2-6600-9898
Release 01 (Sept. 2007)
1
Hard drive not included. An internal SATA drive is required to store or share files. This
enclosure may not work with older generation SATA drives. For a list of SATA drives
that have been tested to work with the DNS-313, visit D-Link support web sites.
2
Note that use of an FTP Server to access files over the Internet does not provide
for secure or encrypted transmissions. It is recommended that the end-user utilize a
Virtual Private Network (VPN) to establish a secure FTP session.
3
Speed results will vary depending on the benchmark utility, hard drive configuration,
and the network environment used for testing.
4
D-Link cannot guarantee full compatibility or proper playback with all Codecs.
Playback capability depends on the codec support of the UPnP AV media player.
EASY HARD DRIVE INSTALLATION – NO TOOLS REQUIRED
1. Remove front panel
3. Re-attach front panel
4. Plug in Ethernet cable 5. Plug in power adapter2. Insert hard drive
Driver Languages
Supported
ACN 052 202 83
8
Z576

D-Link DNS-313 Specifications

Device Interfaces

Gigabit Ethernet port	1 10/100/1000
USB port	1 USB 2.0
Power socket	external power adapter

Operating Environment

Operating temperature	0˚ to 55˚ C (32˚ to 131˚ F)
Storage temperature	-20˚ to 70˚ C (-4˚ to 158˚ F)
Operating humidity	5% to 90% (non-condensing)

Weight and Dimensions

Dimensions	200 (L) x 124 (H) x 49 (W) mm
Weight	1.29 Kg
Supported hard drive type	3.5-inch internal SATA
