D-Link DNS-321

3 D-Link DNS-321 Quick Install Guide
Hardware Overview
Hardware Overview
Front View
Power Button
Drive LED
Drive LED
COMPONENT DESCRIPTION
PowerButton PressoncetopowerontheDNS-321.Pressandholdthebutton
untilitbeginsblinkingtopowerdownthedevice.
DriveLEDs TheseLEDswillbesolidBLUEwhendrivesareconnected.The
LEDswillblinkwhenthedrivesarebeingaccessed,formattedor
synchronized.TheywillilluminateAMBERifadrivehasfailed.
ActivityLED ThisLEDwillilluminatesolidBLUEwhenthereisanEthernet
connection.ItwillblinktoindicateLANtrafc.


Activity LED
