D-Link DSL-2750U Easy Guide

Last few
steps.
If you were accessing the router via Wi-Fi up to this
point, you will need to reconnect to the router
using the new Wi-Fi name and password. It is
important to log out properly by clicking Logout,
and not just shutting down your browser window.
Activate your internet account by opening your web
browser (e.g. Internet Explorer, Google Chrome) and typing
www.telkom.co.za/verifyadsl into the address field.
Press Enter. Complete the fields with your telephone
number and order number and click on Submit.
10
Your router setup is now complete.
Test your internet connection by going to
www.youtube.com/telkom
11 12

D-Link DSL-2750U Specifications

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 12 Mbps
ADSL full rate downstream	up to 24 Mbps
ADSL full rate upstream	up to 1 Mbps

Media Interface

ADSL interface connector type	RJ-11
ADSL interface cable type	24/26 AWG twisted pair telephone line
LAN interface port type	RJ-45
LAN interface standard	10/100BASE-T Ethernet
