D-Link DWL-3600AP Specifications

DWL-3600AP Unied N Access Point
Technical Specications
System
Wi-Fi Interface • 802.11b/g/n 2.4 GHz
LAN Interface • 10/100/1000 Gigabit Ethernet
Antenna • 2x2 MIMO embedded antenna with 4 internal antennas
Antenna Gain • 4.7 dBi
Power Method • IEEE 802.3af Power Over Ethernet or external power adapter
Wireless Frequency • 802.11b/g/n: 2.4 GHz - 2.497 GHz
Data Transfer Rate • 802.11n: 6.5 Mbps-130 Mbps (20 MHz)
6.5 Mbps- 300 Mbps (40 Mbps)
• 802.11g: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps
• 802.11b: 11, 5.5, 2 and 1 Mbps
Operation Channel (2.4 GHz) • 11 channels for United States
System Management • HTTP/HTTPS Web-based User Interface • SNMP, SSH, Telnet Command Line
Security
SSID • 16 SSID • Station Isolation
Wireless Security • WEP • Dynamic WEP • WPA Personal/Enterprise • WPA2 Personal/Enterprise
Detection & Prevention • Rogue and Valid AP Classification
Authentication • MAC Address Filtering • 802.1x
Physical & Environmental
Power Adapter • 5V/2.5A
Power over Ethernet • 48 VDC +/- 10%
Stand-Alone Mode • WEP/WPA/WPA2 Security
• Rogue AP Detection
• Station Isolation
• MAC Address Filtering
• AP Load Balancing Setup
• WDS
• AP Clustering
• QoS/WMM
• Local Storage Configuration
Managed Mode
(Managed by D-Link Wireless Switch/
Wireless Controller)
• Centralized Management
• Centralized Firmware Dispatch
• Visualized AP Management Tool
• Auto-Power Adjustment
• Dynamic Auto-Channel Selection
• L2 Fast Roaming
• L3 Fast Roaming
• Captive Portal
• WEP/WPA/WPA2 Security
• Rogue AP Detection
• Rogue AP Mitigation
• WIDS
• Station Isolation
• MAC Address Filtering
• AP Load Balancing Setup
• WDS
• QoS/WMM
Dimensions • 7.99” x 7.99 “x 1.89” (203 x 203 x 48 mm)
Weight • 1.4 lbs (635 g)
Operating Temperature • 32°F to 104°F (0° to 40°C)
Operating Humidity • 10% to 90% non-condensing
EMI/EMC/RF • FCC Class B
• CE Class B
• C-tick,
• IC
• VCCI
• NCC
• TELEC
• Wi-Fi®
Safety • cUL, LVD (EN60950-1) • UL2043

D-Link DWL-3600AP Specifications

General

Frequency band	2.4 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	300 Mbit/s
Quality of Service (QoS) support	Yes
Data transfer rate	1 Gbit/s
Wireless technology	802.11 b/g/n
Antennas quantity	2
Antenna gain level (max)	4.7 dBi
Internal	No
Certification	FCC, CE
LED indicators	LAN, Power, WLAN
Interface	RJ-45
WAN connection	Ethernet (RJ-45)
Security algorithms	128-bit WEP, 64-bit WEP, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Power supply	8 W
Input current	2.5 A
AC input voltage	5 V

Weight and Dimensions

Weight	635 g
Dimensions (WxDxH)	203 x 203 x 48 mm
