IP Address Configuration
To connect to a network, make sure
the proper network settings are
configured for DWL-G520.
For Microsoft Windows XP:
Go to Start > right click on My Network
Places > select Properties > Double-
click on the Network Connection
associated with the DWL-G520.
Input a static IP address in the same range as
the Wireless Router or Access Point.
Static IP Address setup
Click OK
IP address: 192.168.0.52
Subnet mask: 255.255.255.0
Click OK
Click Internet Protocol (TCP/IP)
Click Properties
Select Obtain an IP address
automatically (if the Wireless
Router or Access Point has DHCP
server enabled)
Select Obtain DNS server
address automatically
Dynamic IP Address setup
Used when a DHCP server is available on
the local network. (i.e. Router)
Used when a DHCP server is not available
on the local network.
Select Use the following IP address
To Next Page
