Hardware Installation
6
To avoid damage caused by static electricity, make sure to
properly ground yourself, by first touching a metal part of your
computer to discharge any static electricity, before working
with the DWL-G520M Wireless PCI Adapter.
A. Make sure to turn off the computer and unplug the power
cord.
B. Remove the back cover of the computer.
C. Install the DWL-G520M carefully and firmly seat it into an
available PCI slot (which is usually white or cream colored).
Installing
the DWL-
G520M
D. Secure the DWL-G520M back panel shield with a screw.
E. Replace the computer’s cover.
F. Place the computer back in its normal position.
