DA Data Cool Series - Line Sizing Chart

24
RECOMMENDED LINE SIZING FOR AIR COOLED SPLIT SYSTEMS
UP TO 200 EQUIVALENT FEET
LIQUID LINES
SINGLE CIRCUIT SYSTEMS
Unit Tons per EQUIVALENT FEET
Tonnage Circuit 50 100 150 200
2 2 3/8 1/2 1/2 1/2
3 3 1/2 1/2 1/2 1/2
SUCTION LINES
SINGLE CIRCUIT SYSTEMS
EQUIVALENT FEET
Unit Tons per 50 100 150 200
Tonnage Circuit HOR VER HOR VER HOR VER HOR VER
2 2 7/8 7/8 7/8 7/8 7/8 7/8 1-1/8 7/8
3 3 7/8 7/8 1-1/8 7/8 1-1/8 7/8 1-1/8 7/8
HOR = HORIZONTAL VERT = VERTICAL
