DA Data Cool Series - Air Cooled Unit Connection Sizes; Remote Condensing Unit Field Piping

9
2.1.3
Connection Sizes, Air Cooled Units
Model Liquid Suction
DACU 02 1/2" 3/4" Note: Unit will have a Liquid Line and
DACU 03 1/2" 3/4" Suction Line
DACU 04 1/2" 3/4"
DACU 05 1/2" 3/4"
Field connections at the indoor evaporator and remote condensing unit will not necessarily be
the same as the field pipe size required. In some cases these sizes will vary significantly.
2.1.4 Field Piping, Remote Condensing Unit
