o291 Function when SL.1, SL.2 or photocell/loop activated 01 - 14 01
01 Presence detection Signal when LOOP1 is activated, remains until LOOP1 is clear.
02 Presence detection Signal when LOOP2 is activated, remains until LOOP2 is clear.
03 Presence detection Signal when both LOOP1 and LOOP2 are activated, remains until either LOOP1
or LOOP2 is clear.
04 Presence detection Signal when PHOTO is activated, remains until PHOTO is clear.
05 Presence detection Signal when PHOTO and LOOP1 are activated, remains until either PHOTO or
LOOP1 is clear.
06 Presence detection Signal when PHOTO and LOOP2 are activated, remains until either PHOTO or
LOOP2 is clear.
07 Presence detection Signal when PHOTO, LOOP1 and LOOP2 are activated, remains until either
PHOTO, LOOP1 or LOOP2 is clear.
08 Presence detection Signal when either LOOP1 or LOOP2 is activated, remains until either LOOP1
or LOOP2 is clear.
09 Direction sensing Signal when rst LOOP1 and then LOOP2 are activated. e signal remains until
LOOP2 is clear.
10 Direction sensing Signal when rst LOOP1 and then PHOTO are activated. e signal remains
until PHOTO is clear.
11 Direction sensing Signal when rst LOOP2 and then LOOP1 are activated. e signal remains until
LOOP1 is clear.
12 Direction sensing Signal when rst LOOP2 and then PHOTO are activated. e signal remains
until PHOTO is clear.
13 Direction sensing Signal when rst PHOTO and then LOOP1 are activated. e signal remains
until LOOP1 is clear.
14 Direction sensing Signal when rst PHOTO and then LOOP2 are activated. e signal remains
until LOOP2 is clear.
