3-3. General Specification
Power Supply
Trans type Power Supply, AC110/220V
(DIP S/W Selectable)
Operating Temperature Range
-10℃ ~ 40℃
Operating Humidity Range
Under 85% Rh (non-condensing)
External Dimension
193mm(W)
ｘ
100mm(H)
ｘ
140mm(L)
Net Weight(kg)
About 2.5kg
Gross Weight(kg)
About 3.0kg
3-4. Option Card
Option No.1
Analogue Output (0~10V)
Option No.2
Analogue Output (4~20mA)
Option No.3
Serial Interface : RS422 / RS485
Option No.4
Option No.5
※ Serial Interface (RS-232C) or Current Loop is Standard installed.
And this DN501A indicator can’t use a BCD IN and OUT card.
3-5. Front Panel (Display & Key pad)
