PAGE 6 / 53
3-5-1. Status Lamp (ANNUNCIATORS) : Green Color Lamp is “ON”.
When the weight is Steady, Lamp is turn on.
When the current weight is Zero, Lamp is turn on.
(Displayed weight is Zero, Lamp is turn on.)
Tare function is set, Lamp is turn on.
(Tare Reset Lamp is turn off.)
Hold Function is Activated, Lamp is ON.
Weighing process is Finished, Lamp ON
When indicator transfers or receives data from other devices, Lamp is turn
on. (If the Lamp is off although there is some data transference, please
check communication settings).
3-5-2. Key Pad Function
Make Weight value as Zero.
Under F08, you can set the Zero key operation range, as 2%, 5%, 10%,
20% or 100% of Max. Capacity.
※ Under “Tare” key input, Zero key will not be activate within operation
range.
Make Weight value as Zero, including Tare Weight.
Under F09, you can set the Tare key operation range, as 10%, 20%, 50%,
or 100% of Max. Capacity.
※ Whenever pressing “Tare” key, you can set the Tare continuously.
Start Weighing process, under Packer Mode, only.
You can set each weighing process as a certain P/N.
And you can call certain P/N with pressing this key.
P/N save : Select P/N and Enter key input.
P/N call : P/N + Number key + Enter
Activate Hold Function, Hold display until Hold Reset input.
