22
Shelf Removal
The shelves in the refrigerator compartment can be easily
removed for cleaning as follows:
• To remove the two upper refrigerator compartment shelves,
lift the front of each shelf up 1 , then push the rear of the
shelf up in back 2 until it clears the shelf holders at the top.
• To remove the lower refrigerator compartment shelf (just
above the crisper drawer), lift it up, turn it at an angle 1 as
shown, then pull it straight out 2 .
Crisper Drawer Removal
• The crisper drawers are attached to the drawer slides with
two thumbscrews. To remove: unscrew the thumbscrews and
lift up on the front of the drawer.
Care and Cleaning
• When replacing each drawer, make sure the back edge
of the drawer slides under the clips toward the rear of the
slides.
FreshZone Freezer Drawer Removal
• The freezer drawer is attached to the drawer slides with two
thumbscrews. Unscrew the thumbscrews and lift up on the
front of the drawer to remove.
• When replacing the freezer drawer, make sure the back edge
of the drawer slides under the clips toward the rear of the
slides.
Ice Container Removal
• The ice container is designed to sit below the ice maker, in
the freezer compartment, on the left side. Lift it up and out to
remove.
• After removal, reposition it correctly, on the left side of the
compartment.
Lower Shelf Removal - Refrigerator Compartment
1
2
Upper Shelf Removal - Refrigerator Compartment
1
2
