Installation instructions
Converting the cooktop burners
NOTE
If you use LP gas, these steps and conversions must be made before adjusting the flames.
1. Lift off the cooktop burner caps and the cooktop burner heads from the cooktop burner
bases or the cooktop burner cups.
Burner Cap
Burner Head
Burner Base
Cooktop Burner Locations
2. Using a /32” or 7 mm nut driver, remove the burner orifice from the bottom of each
burner cup.
Cooktop Burner
Orifice
English 33
