Grill Placement and Use
Page 3
DR30D and ER30D[SR] Ranges
(right burners)
ER30G[I] Range
(right burners)
Line up bottom of grill
with top of grate
Line up bottom of grill
with top of grate
Grease trap
toward back
Grease trap
toward back
Grease trap
toward back
Model ER30D
shown
Put over
center burners
Put over
right burners
Put over
right burners
Line up bottom
of grill with top
of grate
Model ER36D shown. Size and
style varies with model.
DYRP36DS, DYRP48DS,
ER36D and ER48D (center burners)
