de s i g n sp e C i f i C a T i o n s
Dacor®
Model
Number
Overall
Width
“E”
Overall
Height
“F”
Chassis
Depth
“G”
Recess
Width
“H”
Recess
Height
“J”
Recess
Depth
“K”
ECS127
27”
(686mm)
28 3/8”
(721mm)
23 7/8”
5”
(127mm)
5 1/4”
(133mm)
8”
(203mm)
MCS127
ECS130
30”
(762mm)
6 1/4”
(159mm)
PCS130
MCS130
ECS136
36”
(914mm)
28 5/8”
(727mm)
6 3/8”
(162mm)
ECS227
27”
(686mm)
49 7/8”
(1268mm)
5”
(127mm)
MCS227
ECD227
MCD227
ECS230
30”
(762mm)
6 1/4”
(159mm)
PCS230
MCS230
ECD230
PCD230
MCD230
Overall Dimensions
"E"
"F"
1"
(25mm)
"G"
"K"
Recess
1 7/8"
(48mm)
"H"
48"
(1219mm)
"J"
Rotating
elbow
60" (1524mm)
Flexible conduit
1"
(25mm)
"G"
"F"
1"
(25mm)
"K"
1 7/8"
(48mm)
"H"
"E"
"J"
60" (1524mm)
Flexible conduit
Rotating
elbow
1"
(25mm)
Cooktop
Regulator
Recess
26 1/2"
(25mm)
3 5/8"
(92mm)
1"
(25mm)
EPICURE™
1"
(25mm)
MILLENNIA™
2 3/8"
(60mm)
PREFERENCE™
Double Wall Oven
Overall Dimensions
(Epicure Shown)
Single Wall Oven
Overall Dimensions
(Epicure Shown)
Side View -
Handle Projections
pR o d u C T di m e n s i o n s
