Dacor EF36BNDFSS User Manual

2
pR o d u C T di m e n s i o n s
◊ ForEF36seriesmodels,thedepthfromthefrontofthedoor
(w/o door handles) to the back of the refrigerator chassis is
27” (686mm). The depth for IF36 series models is 27 1/4”
(692mm) without paneling
◊ Thedepthofthecabinetlessdooris241/4””(616mm).
◊ Thepowercordis60”(1524mm)long.
◊ Theheightfrom the top of the refrigerator to floor with the
leveling legs in the down position is 69 7/8” (1775mm)
de s i g n sp e C i f i C a T i o n s
in s T a l l a T i o n sp e C i f i C a T i o n s
To o l s a n d pa R T s
IMPORTANT:
◊ Installer: Leave these Installation Instructions with the
homeowner.
◊ Homeowner: Keep these Installation Instructions for future
reference. Save these Installation Instructions for the local
electrical inspector’s use.
Tools needed:
Make sure that you have the necessary tools and materials
available for a proper installation.
◊ Phillips screwdriver set
◊ Slotted screwdriver set
◊ Torx drive screwdriver set
◊ Provide sufficient length 8’ (2.4m) to allow for a minimum of
a 24” (610mm) diameter service loop of 1/4” (6mm) copper
tubing and saddle valve for the water line (Do not use self-
piercing valves)
◊ Copper tubing cutter
◊ Level - 2’ (.6m) and 4’ (1.2m) recommended
◊ Appliance Dolly able to support 700lbs (317kg) and
adequate manpower to handle the weight of the appliance
◊ Various sized pliers
◊ Allen wrench set
◊ 3/8” hex bolt nut driver or socket set
◊ Crescent wrenches
◊ Cordless drill and assorted drill bits
lo C a T i o n Re q u i R e m e n T s
Your Dacor refrigerator can be recessed in an opening between
cabinets or installed at the end of a cabinet run using a side panel
to enclose the refrigerator.
WARNING
EXPLOSION HAZARD – Keep flammable material and vapors,
such as gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
IMPORTANT:
◊ Observe all governing codes and ordinances.
◊ Do not install the refrigerator near an oven, radiator, or other
heat source, nor in a location where the temperature will fall
below 55°F (13°C).
◊ Allow a minimum of 2 1/2” (64mm) space between the side
of the refrigerator and an oven or range.
◊ Floor must support the refrigerator weight, more than 600lbs
(272kg), door panels and contents of the refrigerator.
◊ Ceiling height must allow for side tipping radius.
◊ Location should permit doors to open fully.
◊ The height from the top of the refrigerator to floor with
the leveling legs in the fully extended position is 70 5/8”
(1794mm).
◊ The width from the refrigerator from edge to is 35 5/8”
(905mm).
do o R sw i n g di m e n s i o n s
The area to the left and the right of the appliance must permit
both doors to open to a minimum of 90°. Allow a minimum of 2
1/2” (64mm) space between the side of the refrigerator doors and
a corner wall.
◊ Masonite, plywood, 1/8” pressed fiberboard, cardboard or
other suitable material to protect finished flooring
◊ Appropriate materials to cover and protect the home and its
furnishings during installation

Dacor EF36BNDFSS Specifications

General

Brand	Dacor
Model	EF36BNDFSS
Category	Refrigerator
Language	English
