Daedong 3C093 - Page 47

SPECIFICATIONS 47
87.0 x 92.4
(3.43 x 3.64)
2197
(134.1)
55/2600
(40.5/2600)
1 -3 - 4 - 2
Type
Number of cylnders
Bore and stroke
mm (in)
Total displacement cc (in
3
)
Combustion chamber stroke mm (in)
POWER (GROSS)
HP/rpm (kw/rpm)
Maximum bare speed (rpm)
Minimun bare idling speed (rpm)
Order of firing
Direction of rotating
Injection pump
Injection pressure
Injection timing (before T.D.C)
Compression ratio
Fuel
Vortex chamber
Vertical, water cooled,
4-cycle disedl turbo
4
850
150 ~ 160 kgf/cm
2
(14.7 ~ 157 MPa, 2133 ~ 2276 psi)
12°
Diesel fuel
Counter-clockwise (view from flywheel side)
Bosch K type mini pump
22 : 1
MODEL 4A220T
CAUTION
Specifications are subject to change without
notice.
