SPECIFICATIONS
EXTERNAL DIMENSIONS
※ A1: Overall length including weight
A2: Overall length excluding weight
E1: Front wheel tread
E2: Rear wheel tread
※
Note: These dimensions are measured with the standard
tires (AG) installed to the CABIN model tractor.
C23O301A
Item
CK2620CHSEB
CK3520CHSEB
CK4020CHSEB
1. Overall length (A1) 128.3 (3,260)
2. Overall length (A2) 120.9 (3,070)
3. Overall width (B) 54.5 (1,385)
4. Overall height (C) 92.5 (2,350)
5. Wheel base (D) 65.7 (1,670)
6. Tread (E1) 48.2 (1,225)
7. Tread (E2) 47.6 (1,210)
8. Ground clearance (F) 13.4 (340)
in. (mm)
CABIN
