SPECIFICATIONS
3
3
-
3
※ A1: Overall length including weight
A2: Overall length excluding weight
E1: Front wheel tread
E2: Rear wheel tread
※
Note: These dimensions are measured with the standard
tires (AG) installed to the ROPS model tractor.
B
C
##
D
A
5
F
A
4
#
E
5
E
4
C23O302A
in. (mm)
Item
CK2620(H)
CK3520(H)
CK4020(H)
CK3520(H)SEB
CK4020(H)SEB
1. Overall length (A1) 128.3 (3,260) 128.3 (3,260)
2. Overall length (A2) 120.9 (3,070) 120.9 (3,070)
3. Overall width (B) 54.5 (1,385) 54.5 (1,385)
4. Overall height (C) 92.9 (2,360) 92.9 (2,360)
5. Wheel base (D) 65.7 (1,670) 65.7 (1,670)
6. Tread (E1) 44.3 (1,125) 48.2 (1,225)
7. Tread (E2) 43.4 (1,102) 47.6 (1,210)
8. Ground clearance (F) 13.4 (340) 13.4 (340)
ROPS
