(1) Shuttle Shift Lever (2) PTO Switch
(3) Range Shift Lever (Hi-Low)
(4) Main Shift Lever
3. Place the PTO switch to the “OFF”
position. (It cannot be started en-
gine while the PTO is engaged)
4. Set the main, range and shuttle
shift levers in the neutral position.
6. Set the hand throttle lever to the
“Slow” position. (In case of cold
weather you may adjust it to “Fast”
for easier starting)
7. Depress the clutch pedal. (It can
-
not be started engine when the
clutch is not depressed)
TD2O501S
(1) Position Control Lever
(A) “DOWN”
5. Lower the attachment by pushing
the position control lever forward.
(1) Clutch Pedal
WARNING
Make sure that no one is near
the implement or behind the
tractor.
•
To Next Page
