NS4710 / NS6010 / NS4710H / NS5310H / NS6010H
4
-
26
1
2
3
4
5
6
7
8
9
10
11 12
1
2
3
4
5
6
7
8
9
10
11 12
1313
(1) Hand Throttle Lever
(2) Brake Pedal (L)
(3) Brake Pedal (R)
(4) Tilt Steering Pedal
(5) Parking Brake Lock Lever
(6) HST Forward Pedal
(7) HST Reverse Pedal
(8) Range Gear Shift Lever
(9) Joystick Lever
(10) Double Acting Lever(A,B)
(11) Draft Control Lever
(12) Lift Position Control Lever
(13) Linked Pedal Lever
te7O436a
HST
