DESCRIPTION OF OPERATING SYSTEM
4
-
25
1
3
8
11
12
13
10
9
4
5
2
1
3
8
11
12
13
10
9
4
5
2
6 76 7
OPERATING THE CONTROLS
(1) Shuttle Shift Lever
(2) Hand Throttle Lever
(3) Clutch Pedal
(4) Tilt Steering Pedal
(5) Parking Brake Lock Lever
(6) Brake Pedal (L)
(7) Brake Pedal (R)
(8) Main Gear Shift Lever
(9) Range Gear Shift Lever
(10) Double Acting Lever
(11) Foot Throttle
(12) Lift Position Control Lever
(13) Draft Control Lever
te7O445a
