DAELIM S4 - Transmission Oil Inspection

36
●Start the engine and let it idle for a few
minutes.
●Stop the engine and put the motorcycle
on its mainstand on level ground.
●Check to see if transmission oil leaks
out of the transmission case.
●Fill the recommended oil when you
need.
RECOMMENDED OIL : SAE80W-90
TRANSMISSION OIL CAPACITY : 0.12 ℓ
[SPECIFIED GENUINE OIL]
Check to see if transmission oil leaks out
of the transmission case.
TRANSMISSION OIL INSPECTION
CAUTION
●
Pay special attention not to leak out.
●
When draining the oil, make sure that
all of the oil is removed.
●
The engine can be harmed if there is
too much or not enough oil.
●
Do not use low-quality oil. These
oils can change quality overtime and
can cause damage.
OIL CHECK BOLT
OIL HOLE
CHECK BOLT HOLE
OIL
