24
EXPLODED VIEW AND PARTS LIST
REF NO. R PART CODE PART NAME DESCRIPTION SUPPLY REMARK
A00 DOOR AS
Refer to Disassembly and Assembly
O
B00 CONTROL-PANEL AS O
C00 3512803600 HEATER *T AS KOG-57350S O
F01 3510801310 CABINET PCM O
F02 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN O
F03 3516111900 CAVITY AS KOG-57350S O
F04 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN O
F05 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN O
F06 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN O
F07 35113A5QJ5 CORD POWER AS 3X1.5 80X80 120-RTML 1.4M O
F08 4413A90012 CLAMP POWER CORD NYLON 66 O
F09 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN O
F10 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN O
F11 4414A25110
FUSE
250V 15A 65TS O
4414A25100 250V 15A MDA15 O
F12 3518606100 NOISE-FILTER DWLF-M13 O
F13 7121403011 SCREW TAPPING T2S PAN 4X30 MFZN O
F14 3963513100 MOTOR SHADED POLE 230V 17W OEM-10DWC2-A07 O
F15 3512517000 GUIDE WIND PP O
F16 3511800300 FAN PP+30%GLASS O
F17 R 3518002200 MAGNETRON 2M218H(F) O
F18 3516004000 SPECIAL SCREW T2 BOLT FLANGE 5X12 DACRO O
F19 7272400811 SCREW TAPTITE TT3 TRS 4X8 MFZN O
F20 3513003200 HOLDER HV CAPACITOR SECC T0.6 O
F21 R 3518302200 CAPACITOR HV 2100VAC 0.98UF #187 O
F22 R 3518400400 DIODE HV HVR-1X-3AB 12KV #187 O
F23 R 3518701100 FUSE HV 5KV 0.55A HV-41A55-02 O
F24 R 3518116800 TRANS HV DY-N80S0-63T Q O
F25 3516003700 SPECIAL SCREW TT3 HEX 4X8 FLG MFZN O
F26 3510311700 BASE SBHG T0.8 O
F27 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN O
F28 3512100900 FOOT PP DASF-130 O
F29 7272400811 SCREW TAPTITE TT3 TRS 4X8 MFZN O
F30 3515201101 STOPPER HINGE *U SCP-1 T2.5 O
F31 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN O
F32 R 3518570400 SWITCH S/A RELAY DWSR-1 O
F33 R 4415A17352 SW MICRO VP-533A-OF SPNO #187 200G O PRIMARY
F34 R 4415A66910 SW MICRO VP-531A-OF/SZM-V16-FA-61 O MONITORY
F35 R 4415A17352 SW MICRO VP-533A-OF SPNO #187 200G O SECONDARY
F36 3513702600 LEVER LOCK POM O
F37 3513811710 LOCK POM BLACK O
To Next Page
