Pin Name
Symbol
Description
A* B* A* B* A* B*
30 CVBS CVBS CVBS IN
31 P2.3/8 bit ADC Not Used
32 22 P2.2/8 bit ADC B0/AN0/ADC AGC IF AGC INPUT for Auto Tuning System
33 23 P2.1/8 bit ADC B1/AN1/ADC KS Local KEY SCAN IN
34 24 P2.0/8 bit ADC B2/AN2/ADC S/SW Not Used
35 25 VSS VSS-OSD VSS Ground
36 26 P3.3/INT1 INT1 IR REMOTE IR IN
37 27 VDD VCC-OSD VDD Power Supply
38 28 LCIN OSCIN-OSD LCIN CLOCK IN for OSD
39 29 LCOUT OSCOUT-OSD LCOUT CLOCK OUT for OSD
40 30 P3.7/TXT I/O T2EVT/PWM2 BL BAND VHF-L OUT ( Active High )
41 31 P3.6/RXD T2IC2/PWM1 BH BAND VHF-H OUT ( Active High )
42 32 P3.5/T1 T2IC1/CR BU BAND UHF OUT ( Active High )
43 33 P3.4/T0 T1EVT/PWM2 POWER POWER CONTROL OUT
44 34 P3.2/INT0 INT2 Not Used
45 35 HS/SC HSYNC HSYNC HOR. SYNC. IN (Active High)
46 36 P4.7/VS VSYNC VSYNC VERT. SYNC. IN (Active High)
47 37 R R RED OUT
48 38 G G GREEN OUT
49 39 B B BLUE OUT
50 40 BLANK BL BLANK OUT
51 41 COR COR Not Used
(CONTRAST REDUCTION OUT)
52 42 P3.0 T1C2/PWM1 EVEN/ODD EVEN/ODD OUT for non-interlacing
in TTX mode
To Next Page
