Daewoo 14Q1 - IC 1501 DC Voltage Readings; Other IC DC Voltage Readings

48
• I301(TDA8356)
• I502(TDA4665)
• I503(TDA8395)
• I802(TDA8138)
• I501(TDA8374A)
PIN NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14
V(DC) 0 3.8 3.6 3.6 2.8 3.0 4.6 4.6 6.64 0 3.4 8.0 100mv G
PIN NO 15 16 17 18 19 20 21 22 23 24 25 26 27 28
V(DC) 3.76 3.7 3.5 5.3 2.5 3.8 2.7 3.1 3.4 3.4 3.4 0 2.5 2.5
PIN NO 29 30 31 32 33 34 35 36 37 38 39 40 41 42
V(DC) 1.7 1.7 4.0 4.0 1.6 2.6 2.6 4.6 8.0 3.4 6.0 3.0 0 4.8
PIN NO 43 44 45 46 47 48 49 50 51 52 53 54 55 56
V(DC) 4.0 G 8.0 2.3 2.3 4.2 4.2 0 3.9 4.0 3.7 3.4 3.2 4.7
PIN NO 1 2 3 4 5 6 7 8 9
V(DC) 2.3 2.3 16.8 8.0 0 44 8.1 0 8.1
PIN NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
V(DC) 5.0 0 0 0 0 0 1.0 0 5.0 0 2.9 2.9 0 1.4 0.7 114
PIN NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
V(DC) 1.6 1.2 7.9 0 0 0 3.3 4.2 1.7 1.7 0 0 0 0 0.7 2.8
PIN NO 1 2 3 4 5 6 7 8 9
V(DC) 13.0 14.0 3.0 4.82 G 5.05 0 11.98 5.05
