52
LOC. PART-CODE PART-NAME PART TYPE REMARK
Z503 5PTPS60MB- FILTER CERA TPS 6.0MB(EFC-S6ROME3)
Z504 5PTPS65MB- FILTER CERA TPS 6.5MB(EFC-S6R5ME3)
ZZ200 PTMPJ0A499 PCB MAIN (RHU) AS DTC-14Q1VM
C308 CEXF1E471C C ELECTRO 25V RUS 470MF (10X16) TP
C412 CEXF2C339V C ELECTRO 160V RSS 3.3MF (8X16) TP
C417 CEXF2E330V C ELECTRO 250V RSS 33MF (13X25) TP
C427 CCXB3D471K C CERA 2KV B 470PF K (TAPPING)
C428 CEXF2C470V C ELECTRO 160V RSS 47MF (13X25) TP
C615 CEXF1V331C C ELECTRO 35V RUS 330MF (10X20) TP
C809 CEXF1E331V C ELECTRO 25V RSS 330MF (10X12.5)TP
C818 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
C819 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
C821 CEXF1V102V C ELECTRO 35V RSS 1000MF (13X25) TP
C823 CEXF1E222C C ELECTRO 25V RUS 2200MF (16X25) TP
ZZ200 PTMPJBA499 PCB MAIN M-10 AS DTC-14Q1VM
L104 58E0000S37 COIL AFT TRF-A001
P101 485923162S CONN WAFER YW025-03 (STICK)
P102 485923162S CONN WAFER YW025-03 (STICK)
P501 485923192S CONN WAFER YW025-06 (STICK)
P502 485923172S CONN WAFER YW025-04 (STICK)
P601 485923162S CONN WAFER YW025-03 (STICK)
R303 RS01Z153J- R M-OXIDE FILM 1W 15K OHM J (TAPPING)
R307 RS02Z271J- R M-OXIDE FILM 2W 270 OHM J (TAPPING)
R408 RS02Z561J- R M-OXIDE FILM 2W 560 OHM J (TAPPING)
R409 RS01Z103J- R M-OXIDE FILM 1W 10K OHM J (TAPPING)
R415 RF01Z129J- R FUSIBLE 1W 1.2 OHM J (TAPPING)
R720 RS02Z562JS R M-OXIDE FILM 2W 5.6K OHM J SMALL
R759 RS02Z562JS R M-OXIDE FILM 2W 5.6K OHM J SMALL
R805 RS02Z363J- R M-OXIDE FILM 2W 36K OHM J (TAPPING)
R811 RS01Z240J- R M-OXIDE FILM 1W 24 OHM J (TAPPING)
R812 RF02Z338J- R FUSIBLE 2W 0.33 OHM J (TAPPING)
R814 RS02Z563J- R M-OXIDE FILM 2W 56K OHM J (TAPPING)
R824 RS02Z430JS R M-OXIDE FILM 2W 43 OHM J SMALL
R825 RS02Z330J- R M-OXIDE FILM 2W 33 OHM J (TAPPING)
ZZ200 PTMPJRA499 PCB MAIN RADIAL AS DTC-14Q1VM
CA04 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
CA05 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C103 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C104 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C105 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C107 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C109 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C111 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
