1 IC DRIVER 1PT6524--- PT6524--- QFP 1 EA IC700
2 SW TACT 5S52643CL2 1C-1P SKMA 10918A 260G 18 EA HS701 HS702 HS703 HS704 HS705
HS706 HS707 HS708 HS709 HS710
HS711 HS712 HS713 HS714 HS715
HS716 HS717 HS718
3 ENCODER VOLUME 5V3503A71A EC22B20-ZZZ 1 EA SW700
4 LCD BLACKMASK 97T0L2150N 91709BMM1TTN 1 EA LCD70
5 CONN ZEBRA 97T6229600 -- 1 EA 0F050
6 CONN-FLIP(PLUG) 97T6235000 FPP1444X 1 EA CW1
7 PCB FRONT 97T65A83FR SILVER 164X40X1.6T 1 EA B002
8 LED DSB3317G-- SB3317GB-BLUE 1 EA HL718 HL719 HL720
9 LED CHIP DSY1216C-- SY1216-C 18 EA HL700 HL701 HL702 HL703 HL704
HL705 HL706 HL707 HL708 HL709
HL710 HL711 HL712 HL713 HL714
HL715 HL716 HL717
10 FR CHIP AS DON N5FC01156P KOR-1156 1 EA 00FC1
11 FRONT AS DON N5FR01157P KOR-1157 1 EA 00FR1
12 PCB FRONT AS AUTO CHIP PNFRJCNI00 AGC-5200AD 1 EA 11002
13 PCB FRONT AS PNFRMBNI01 AGC-5200RD 1 EA 11001
NAME CODE
Q ty
Description Location
FRONT DETA ASPNFDCANI01 AGC-5200RD
Parts List for AGC-5200
42
1 PCB ISO 97T659661S 160X137.5X1.6/9 1 EA B006
2 CONN AS 97T8856100 ISO 16P WITH 10A FUSE 1 EA CW105
3 ISO ASS'Y DON N51S00115P KOR-115 1 EA 00IS1
NAME CODE
Q ty
Description Location
PCB ISO AS PN1SMBJA06 AKD-0225H-AX
1 SW TACT 5S52625MP1 TP1140B 1 EA SW701
2 PLATE PCB 97T0929500 PC 1 EA 0D010
3 CONNECTOR 97T6234900 FPS1442X(SOKET) 1 EA CWFR
4 PCB ESC 97T65A88ES 160X118XT1.6/3 1 EA B0004
5 LAMP PILOT 97T82L6F95 9V 50MA D3.0 C3RDHT003 1 EA PL701
6 CONN AS 97T8879500 FFC 14P 1.25MM PITCH 50MM 1 EA CN101
7 ESCUTCHEON AS DON N5ES00773P KOR-773 1 EA 00ES1
8 ESC PCB AS PNESMBNI00 AGC-5200 1 EA 21001
NAME CODE
Q ty
Description Location
ESCUTCHEON AS PNESCANI00 AGC-5200, 5240RD-AS
