1 CONN AS 97T8858300 "ISO 16P W/PHON,ILL" 1 EA CN200
2 LABEL CONNECTION 97T9319710 STICKER 3A 1 EA PK150
3 LABEL BAR CODE 97T9322610 STICKER 1 EA PK220
4 LABEL CLASSIC 97T93275GD STICKER 1 EA PK200
5
MANUAL INSTRUCTION
97T9514500 ART PAPER REF.DES 1 EA PK160
6
ASSCESSORY AS DON
N5AC00036P KOR-36 1 EA 00AS1
Parts List for AGC-5200
43
1 IC CHIP DRIVER 1389259ED- KA9259ED 1 EA IC5
2 IC REGULATOR SMD 1BA33C18FP BA33C18FP(3.3V/1.8V) 1 EA IC6
3 IC SDRAM 1HY57V1616 HY57V1616 1 EA IC2
4 IC SSP 1S1L9226-- S1L9226 1 EA IC1
5 IC CHIP DSP 1S5L9279-- S5L9279 DSP+DECODER 1 EA IC3
6 SWITCH DETECT 97L0S00600 MPU10853MLB4 1 EA SW1
7 DECK MECHANISM 97T6013200 CDX-200DW 1 EA DK010
8 CONNECTOR 97T6237600 08-6224-016-001-800 1 EA CN1
9 CONN WAFER 97T6245500 20010WR-0400 1 EA CN2
11 CONN WAFER 97T6245700 FCZ100E-32RS-K 1 EA CN3
12 PCB SERVO 97T65A81SE 247X197X1T/4(MP3) 1 EA B0001
13 CONN AS 97T8879600 FFC 32P 1MM PITCH 160MM 1 EA CN102
14
CHIP SOLID INDUCTOR
HLP100D24B LK2125100K-T 10UH 5 EA L1 L2 L3 L4 L5
15 CRYSTAL CHIP HXB16R93ME SMD 16.9344MHZ 30PPM 1 EA X1
16 CD DECK AS DON N5DC01024P KOR-1024 1 EA 00DC1
17 CD DECK AS DON N5DK00662P KOR-662 1 EA 00DK1
18 MP3 DECK AS PNDKCALQ03 CDX-400F AGC-5200 1 EA 22001
19
MP3 DECK TOTAL AS
PNDTCALQ01 CDX-400F 1 EA 22002
20
PCB SERVO AS AUTO CHIP
PNSVJCLKB3 CDX-400F BOTTOM 1 EA 10003
21
PCB SERVO AS AUTO CHIP
PNSVJCLKT3 CDX-400F TOP 1 EA 10002
22 PCB SERVO AS PNSVMBLK03 CDX-400F AGC-5200 1 EA 22003
23 TR TKSB772Y-- KSB772Y 1 EA Q2
24 TR CHIP TKTA1505YB KTA1505-Y 1 EA Q1
NAME CODE
Q ty
Description
Location
DECK AS PNDKCANI00 AGC-5200, 5240RD-AS
1 COVER BOTTOM 97T0440300 SECC T=0.6 1 EA CH020
2 COVER TOP 97T0440410 SECC T=0.6 PI 1 EA CH030
3 CHASSIS MAIN 97T0635200 SECC T=1.0 1 EA CH010
4 HEAT SINK 97T4412000 DIECASTING(ALDC-12) 1 EA CH050
NAME CODE
Q ty
Description Location
CHASSIS MAIN AS PNCHCANI00 AGC-5200, 5240, 5280
NAME CODE
Q ty
Description
Location
PACKING AS PNPKCANI01 AGC-5200, 5240RD-AS
To Next Page
