Daewoo AGC-5200 RDS User Manual

1 IC AUDIO 1BU1924F-- BU1924(SOP) 1 EA IC204
2 IC RESET 1K1A7032AT KIA7032AT/TSM 1 EA IC302
3 IC CHIP REGULATOR 1K1A7808AF KIA7808AF DPARK 1 EA IC111
4 IC REGULATOR 1K1A7808P1 KIA7808API 1 EA IC301
5 IC AUDIO 1PT2313L-- PT2313L 1 EA IC202
6 IC CHIP CUSTOM 1S3P831B00 S3P831 BXZZ-QXRB 1 EA IC201
7 IC POWER 1TDA8571J- TDA8571J-Y 1 EA IC203
8 COIL CHOKE 5LC301PA18 37X1X5.2 300UH P EI-19MM 1 EA CH601
9 COIL INDUCTOR 5LL479K03K 4.7UH K 03 TA 26MM 1 EA L401
10 CRYSTAL QUARTZ 5XJZ4R332D HC-49/S 4.332MHZ 25PPM F 1 EA XT501
11 CRYSTAL QUARTZ 5XJZ9R000D HC-49S 9MHZ 30PPM 1 EA XT401
12 CON DETACHABLE(CNDT) 97T62150A0 FP.S-12-3.2-GG 1 EA U1
13 CONN WAFER 97T6245700 FCZ100E-32RS-K 1 EA CW201
14 PCB MAIN 97T65A83MA 330X190X1.6T/2 FR-1 1 EA B0001
15 JACK ANT 97T6802500 9.5X20X27.5 1 EA ANT01
16 TUNER FM/AM 97T7612800 KST-M4001LVO-10 1 EA TU101
17 CONN AS 97T8865000 E3P 100M/M 1 EA CW1
18 DIODE CHIP DKDR729--U KDR729-USC 2 EA HD201 HD206
19 DIODE CHIP DKDS160--B KDS160-UF 16 EA HD1 HD101 HD202 HD205 HD207
HD301 HD306 HD601 HD605 HD606
HD610
20 LED DLT4H11G41 LT4H11G-41(RED) 1 EA LD01
21 DIODE CHIP DRF101L2SB RF101L2S 6 EA HD410 HD603 HD604 HD607 HD611
HD613
22 DIODE RECTIFER CHIP DS3DD0214D 3A SMD RECTIFER 1 EA HD612
23 DIODE CHIP ZENER DZKDZ100V- KDZ 10V USC 1 EA HZ301
24 DIODE CHIP ZENER DZKDZ5R1V- KDZ5.1V USC 3 EA HZ102 HZ601 HZ602
25 DIODE CHIP ZENER DZKDZ5R6V- KDZ5.6V USC 2 EA HZ401 HZ604
26 DIODE CHIP ZENER DZKDZ9R1V- KDZ9.1V USC 1 EA HZ101
27 MAIN CHIP AS DON N5MC01712P KOR-1712 1 EA 00MC1
28 PCB MAIN AS AUTO CHIP PNMAJCNI04 AGC-5220RT 1 EA 10002
29 PCB MAIN AS AUTO PNMAJMNI04 AGC-5220RT 1 EA 10001
30 TR CHIP TDTA123JKA DTA123JKA (E32) 1 EA HQ101 HQ102
31 TR CHIP TDTC323TKB DTC323TK 1 EA HQ610 HQ611
32 TR CHIP TKRA101S-B KRA101S 1 EA HQ608
33 TR CHIP TKRC102S-B KRC102S 6 EA HQ103 HQ104 HQ202 HQ205 HQ605
HQ609
34 TR CHIP TKRC107S-B KRC107S SOT-23 NU 1 EA HQ1
35 TR CHIP TKRC111S-B KRC111S 1 EA HQ105
36 TR TKSB772Y-- KSB772Y 1 EA HQ607
37 TR CHIP TKTC3295B- KTC3295B RTK 2 EA HQ107 HQ108
38 TR CHIP TKTC3875YB KTC3875Y SOT-23 ALY 2 EA HQ301 HQ606
39 TR TZ2SB1240R 2SB1240R 1 EA HQ204
40 TR TZDTC323TS DTC323TSA SPT 1 EA HQ601
41 TR TZTC3198Y- KTC3198Y-(1815Y) (AUTO) 1 EA HQ401
42 TR TZTC3199Y- KTC-3199Y TAPING 1 EA HQ302
43 TR TZTC3205Y- KTC3205Y (2236Y) 1 EA HQ106
44
PCB MAIN AS PNMAMBNI04 AGC-5220, 5260
NAME CODE
Q ty
Description Location
Parts List for AGC-5220

Daewoo AGC-5200 RDS Specifications

General

Brand	Daewoo
Model	AGC-5200 RDS
Category	Car Receiver
Language	English
