Daewoo B25S-2 Disassembly/Assembly

Vehicle Systems Disassembly & Assembly
5.
Install springs (7) and seals (8) on the valve
spools.
6. Install lift and tilt spool assemblies (9) to the valve
body.
7. Install O-ring seals (10) to the valve body.
8. Install seal (11) and spring (12) to the attachment
valve spool (13).
9. Install valve spool (13) to the valve body.
10. Install retainer (14), dust cover (15) and bolt (16)
to each section.
11. Install bolts (17) to assemble the valve sections.
45
IDCD222P
8
8
9
7
IDCD221P
10
10
10
10
10
10
IDCD219P
13
12
11
IDCD226P
IDCD216P
17
14
15
16
