Daewoo BC25S-2 Disassembly/Assembly

Vehicle Systems Disassembly & Assembly
3.
Remove side shift spool (7) from the valve body.
4. Remove seal (8) and spring (9) from the valve
spool.
5. Remove O-ring seals (10) from the valve body.
6. Remove lift and tilt valve spool assemblies (11)
from the valve body.
7. Remove seals (12) from the valve spools.
8. Remove springs (13) from the valve spools.
9. Remove plug (14) and spring (15).
10. Remove hydrostat (16).
43
IDCD219P
IDCD221P
8
9
10
10
10
10
10
10
7
IDCD222P
IDCD223P
11
13
15
16
14
12
12
