1. Oil plugφ28*6
2. Bearing6002
3. Change gear
4. Mainshaft
5. Bearing6202
6. Elastic circlip for hole D=φ35
7. Oil sealφ15*φ35*7
8. Hexagon socket cahead screws M6×12
9. Hexagon socket cahead screws M6×12
10. Hexangular boltM6×16
11. Gear shifting fork shaft
12. Gear shifting fork shaft
13. Oil sealφ12*φ22*6
14. Bush φ20.5*φ25.5*11
15. Reverse gear
16. Transition spur gear
17. Countershaft
18. Oil plug φ16*5
19. Iron shot Sφ6.35
20. Positioning spring
21. Bushφ30*φ34.8*7
22. Sealing O-ringφ40*φ2.5
23. Duplex spur gear
24. Driving chain wheel shaft
25. Driving chain wheel
26. Bushφ18.3*φ23*23
27. Transition spur gear
28. Nonstandard washerФ17×Ф26×2
29. Bearing6203
30. Oil scale
31. Transmission case body
32. Bush φ35*φ39.8*7
33. Sealing O-ringφ40×φ2.5
34. Oil sealing plate
35. Hexangular boltM6×12
36. Gearbox cover
37. Oil sealφ25×φ41×13.5
38. Bearing 6005
39. Chan 56knots
40. Driven sprocket
41. Output shaft
42. Bearing 6205
43. Elastic circlip for hole D=52
44. Oil sealφ25×φ52×13.5
45. Gearbox cover
46. Oil drain bolt M12×1.5×16
