4. ASSEMBLY
Assembling the saw bar and saw chain
– Lay the saw on flat surface.
– Turn the fastening bolt (5) anti-clockwise and loose the chain adjustment ring（4）to remove the
sprocket chain wheel cover（14）.
– To fit the new bar, place the bar (3) onto the bar bolt (16) with the tensioning plate (15) pointing
outwards.
Note:
When attaching the chain, heed the correct position of the guide groove (saw rail).
– Spread the chain (2) out into a loop with cutting edges running clockwise. Relax the tensioning
plate (15) against the clockwise direction.
– Slide the saw chain (2) into the bar guide groove. To mount the Chain bar (3),raise it to an angle of
approx..45 degrees. This will make it easier to replace the saw chain (2) onto the sprocket (17). It is
normal that the saw chain (2) is slack. Sagging in the chain is normal. .
– Pre-tighten the chain (2) by turning the tensioning plate (15) clockwise.
– Position the sprocket chain wheel cover (14). Only lightly tighten the fastening bolt (5) , as you will
still have to tension the saw.
DANGER!
Risk of injury during operation!
Improperly mounted parts can cause severe and even fatal injuries when using the device!
This device may only be commissioned if all parts are mounted completely and tightly and
no part is damaged!
• Therefore, read the whole chapter before you assemble the parts!
• Assemble the parts carefully and completely.
• Use tools when their use is suggested.
WARNING!
Risk of injury during assembly!
Parts may only be assembled and disassembled when the motor is switched off (de-energi-
se device).
CAUTION!
Risk of injuries due to cuts!
The teeth of the saw chain are very sharp! Protective gloves must be worn for all work on the
chain.
DANGER!
Risk of injury!
An improperly mounted saw chain causes uncontrolled cutting behav- iour of the device!
When assembling the chain, heed the prescribed run- ning direction!
