Cleaning and maintenance overview
After each use
Regularly, depending on the conditions of use
Cleaning
Cleaning the device
– Remove coarse dirt.
– Wipe down the device with a slightly damp cloth.
Cleaning the oil guide groove of the saw rail
– Remove the saw rail.
– Clean dirt from the oil guide groove of the saw rail with a suitable tool.
– Replace saw bar Assembling the saw bar and saw chain – p. 11).
Re-tensioning the saw chain
P. 5, item 6
– Loosen the fastening bolt (5) by approxi- mately one turn.
– Lift the tip of the saw bar slightly.
– Tighten the Chain Adjustment Ring for chain tension (4) until the chain lies on the underside of the
saw rail.
Lubricating chain wheel
P. 6, item 9
The bearing of the chain wheel should be regularly lubricated at the front-end of the rail. About 1× in
a week in case of intensive use.
– Clean the lubrication hole.
– Apply little multi-purpose grease in the lubrication hole, while moving the chain with hand.
What?
How?
Clean the device ► Cleaning the device - P.16
What?
How?
Re-tension saw
► Re-tensioning
Clean oil guide
groove of the
saw rail
Cleaning the oil guide
groove of the saw rail – p. 16
►
Sharpen the
saw chain
Sharpening the saw
chain – p. 17
►
NOTICE!
Device damage!
To clean the saw rail, use only a plastic spatula, never a steel tool.
