- 101 -
4) DE12TIS
(1)DE12TIS
(a) Main data and specifications
Part No. : 65.11101-7661(108622-4000)
Model : HD-TICS
Governor : RLD+J type
Timer : Dummy timer + electronically controled
Plunger :
Delivery valve : 65.11108-6009
Fuel feed pump: 65.12101-7013
Pre-stroke : 6.3L0.05mm
Rotating direction : C.W. at driving gear side
Injection order : 1-5-3-6-2-4
Injection timing : BTDC 1°
(b) Calibration data
Adjusting
Rack position Pump speed Injection volume
Variation Basic Fixing Ref.
point (mm) (rpm) (mm
3
/1,000st) rate (%) point point
A R1 1,050 158.0L2 L20
B R1-1.5 630 162.3L3 L15
C R1-1.85 500 173.8L3-
IR2L2.0 100 45.8 -
H R2 300 2.3 -
Contents Specifications Engine application
Nozzle holder assembly 105780-8250 65.10101-7298
Nozzle 105780-0120
Nozzle holder 105780-0120
Opening pressure 220 kg/cm
2
1st : 160, 2nd : 220 kg/cm
2
Injection pipe N8 B N3 - 600mm N6 B N2.2 - 600mm
Fuel delivery pressure 2.6 kg/cm
2
Fuel temperature 35~45 C
Adjusting
conditions
