Daewoo DE12 - Page 23

- 20 -
1.5.8. DE12TIS - for Bus
EA2M1005
18
11
4
6
15
71 233 31205
1735 22 21 16938
10 2912 12 341325
24 32 19 1426 23 3027 28
1. Cylinder block
2. Flywheel housing
3. Breather
4. Oil filler pipe
5. Vibration damper
6. Flywheel
7. Crank shaft pulley
8. Cylinder head
9. Cylinder head cover
10. Oil filter
11. Oil cooler
12. Oil pan
13. Oil dipstick
14. Cooling water pipe
15. Water pump
16. Exhaust manifold
17. Heat screen
18. Intake manifold
19. Intake stake
20. Turbocharger
21. Air pipe, A/C-T/C
22. Air pipe, T/C-A/P
23. Air pipe, A/P-I/C
24. Injection pipe
25. Injection pump
26. Pick-up sensor
27. Prestroke actuator sensor
28. Rack sensor
29. Injection pump bracket
30. Fuel filter
31. Starter
32. Air heater
33. Engine mounting bracket
34. Power steering pump
35. Air compressor
