(3) Measuring clearance between drive shaft and bushing
a. Measure the outside diameter of the drive shaft and driven shaft, and replace if the mea-
sured values are less than the limit (N16.95mm).
b. Measure the inside diameter of the pump body bushing to determine the clearance
between the bushing and shaft, and compare the measured value with the standard
value to determine whether to replace or not.
(Clearance : 0.032~0.077mm)
3) Reassembly
(1) For reassembly, reverse the disassembly sequence.
4.2.3. Oil filter
The oil filter mounted in this engine is of cartridge type, so it is necessary to replace it with a
new one at the specified intervals.
- 86 -
