(6) Performance curve of governor
- 127 -
MAINTENANCE OF MAJOR COMPONENTS
Rack position(mm)
Rack position(mm)
14 more
6.3
R1+0.5
R2(R1+0.5)
(R2 - 0.7)
Pump speed(rpm)
Boost pressure(mmHg)
N = 500 rpm
A
C
B
0 300 500 850 (1020) 1100
1040
11.4
+
_
0.1
10.6
+
_
0.1
5.4
+
_
0.1
8.9
+
_
0.1
Idle sub spring set.
+
_
0.1
Boo. com stroke : 0.7 mm
0 (500)
+
_
10
300
EE6OM040
NOTCH : 14 NOTCH
