Installation instructions
Caution
Installation of flue system
Forced exhaust type : FE
Install the boiler in a room reserved for the boiler only
The forced exhaust type boiler must be installed in a room reserved for a boiler only.
The boiler room means the space designated for a boiler only, separate from living
spaces or spaces used for other purposes.
The boiler room needs access to an air inlet and an outlet for ventilation.
Warning
The diameter of flue duct : Φ80mm
slope 3
o
above 60cm
above
15cm
above 15cm
above 50cm
outlet for
ventilation
incombustibles
air inlet
Install a terminal guard to protect the terminal from mechanical damage from
outside influences. (such as birds or rats)
There must be no flammables within 60cm from the terminal. (within 30cm
in case heat resistant boards are installed)
Make sure there is no hole within 60cm which allows flue gas to re-enter.
A 3° downward slope is required to keep precipitation off.
Total length of ducts must be less than 5m, with no more than 3 turns.
(not including the initial turn at the terminal / no ducts must be bent upwards)
flue duct
28
