34
Chimney Assembly
DGB-80L - Dual pipes type chimney
DGB-80C - Co-axial pipes type chimney
1. Assembly of Dual pipes type Chimney (DGB-80L)
Diameter of Air supply duct 110mm
Diameter of Gas flue duct 80mm
Cover in flue 110
Duct in flue 80
Duct out flue 80
Packing duct in
How to install Dual pipes type Chimney(DGB-80L) to the boiler
1) Assemble Duct in flue 80 and Cover in flue 110 to Boiler’s Frame with screws as an above left picture.
2) Insert Chimney(DGB-80L) to Boiler’s Duct in flue 80 and Duct out flue 80 as an above right picture.
2. Assembly of Co-axial pipes type Chimney (DGB-80C)
Diameter of Air supply duct 110mm
Diameter of Gas flue duct 80mm
Steel band
Packing duct in
Cover duct in 80
How to install Co-axial pipes type Chimney(DGB-80C) to the boiler
1) Assemble Cover duct in 80 to stop up a Duct in flue’s hole.
2) Assemble Duct in flue 110 to Duct out flue with screws.
Duct out flue 80
Duct in flue 110
3) Insert Chimney(DGB-80C) to Boiler’s Duct in flue 80 and Duct in flue 110 as an above left picture.
4) Fix steel bands to Chimney(DGB-80C) to do not escape Chimney from boiler as an above right picture.
