Room Controller Display(DBR-W21)
When Room temperature(house icon) in temperature
setting is selected,
When Heating water temperature(radiator icon) in
temperature setting is selected,
Set Room temperature display
Shows the set room temperature that you desire.
(Set temperature can range from 5 C~40 C.)
o o
Current temperature display
Shows the current room temperature when you use heating,
or shows the current hot water temperature when you use hot water.
Heating timer indicator
Shows when you press the Heating timer button.
Room temperature indicator
Shows when the room temperature function
in temperature setting is selected.
Hot water indicator
Shows when the Hot water function is selected.
Rapid Hot water indicator
Shows when the Rapid hot water function is selected.
Going-out indicator
Shows when Going-out (anti-freezing mode) is selected.
Current time display
Shows the current time.
Heating timer indicator
Scheduled times are set on an hourly basis.
The programmed set times are marked in black.
Week indicator
Shows a day of week when the week timer is selected.
(No display when use for 24 hours timer only.)
Set Hot water temperature display
Shows when you press the Hot water button.
(Set temperature can range from 35 C~60 C.)
o o
Heating water temperature indicator
Shows when the heating water temperature function
in temperature setting is selected..
Set Heating water temperature display
Shows the set heating water temperature that you desire.
(Set temperauture can range from 45 C~80 C.)
o o
Current temperature display
Shows the current heating water temperature when you use heating,
or shows the current hot water temperature when you use hot water.
