3
1. PARTS LIST
1. Upper handle
2. Lower handle
3. Switch box
4. Grass collection box
5. Wheels
6. Motor cover
2. TECHNICAL DATA
Rated Power: 230V-240V-50Hz,2000W
Motor type: Brush motor
Cutting width: 420mm
No-load speed: 3450rpm
Central adjustment: 5 height positions with 25-80mm
Collection bag: 40L Plastic
Wheels: front 6.0”; rear 9.0” (PP wheels with cover)
*with mulching function
*with handle adjust(angle adjust)
This tool is double insulated. There are two independent barriers of
insulation to protect you from the possibility of electric shock.
NOISE DATA: Declared guaranteed sound power level: 96dB (A)
The sound intensity level for operator may exceed 85dB(A) and ear
protection measures are necessary
3. SAFETY INSTRUCTIONS
GENERAL SAFETY INSTRUCTIONS
WARNING! Read all instructions failure to follow all instructions
listed below may result in electric shock, re and /or serious
